- Static or dynamic weighing of packs, both automatically as well as semiautomatically with the operator.
- Management of the cadence belt, for optimising the number of packs per minute weighed by the instrument (cadence belt not included), through cadence photo cell (optional).
- Setting of the density coefficient for each article, for weighing in ml.
- Programmable alarm enabling and tolerance indication time.
- Tolerance check:
- Upon target, through article database, with setting of 3 tolerance thresholds, for the physical division of the packs into 7 different groups.
- Upon programmable weight thresholds (min/max), with article database.
- Upon weight thresholds (min/max), with quick entry function.
- Printout with each executed weigh with eventual automatic storage in the alibi memory.
- Automatic printout and clearing of the partial total after a programmable number of weighs.
- Static or dynamic automatic zero function of the belt (up to 2% of the capacity) after a programmable number of weighs.
- Management of the automatic expulsion through its specific relay contact (expeller not included in the supply), or halt of the belts for manual expulsion or weight correction.
- Possibility of connection to RS485 network or ethernet.
- Programmable preset tare and enabling delay of the expeller for each article.
- Automatic calculation of the weigh time and pack positioning, for optimising the functioning of the system.
- Database of 1000 articles, with programmable alphanumeric description, density, targets, tolerance thresholds, and preset tare for each article.
- Selection of the article through bar code reading.
- Advanced bar code management, with the possibility of storing, processing, and printing 5 different codes.
- Configuration and calibration of the instrument through the tool on the PC.
- Report with date and time of cycle beginning and end with statistics of the checks and/or activities, standard deviation of the executed weighs, and totals by class and/or article.
- Possibility of connection to a control light.
|
